Features/Applications
DM-PVC/H is a rigid, shiny, lay flat, thin wall, PVC, heat shrink tubing.
DM-PVC/H offers a good resistance to chemical fluids and a good mechanical stiffness.
DM-PVC/H is suitable for packaging of electronic or electric components and could
replace paint coating on LV bus bars.
Various
Standard colors: Black, Blue, Clear.
Special colors available on request,
shrink raito: 2:1

Technical Data

Property		Test Method	Values
Working temperature			-20°C to+85℃
Longitudinal change			-10% maxi
Tensile strength	Unaged	ASTM D 638	≥10 MPa
Elongation at break			≥42%
Heat resistance	1000h @105℃		No crack
Dielectric strength		ASTM D 149	≥15 kV/mm
Volume resistivity		ASTM D 257	≥1014 Ω·cm
Water absorption		ASTM D 570	≤2.0%

Dimensions
These parts can be tailor-made to each customer's application.
• Flat width: 5 to 580 mm
• Thickness: 40 to 200 microns
• Finish: Shiny, matt or satin
• Spools as standard, cut pieces available on request
