Applications
Spiral wrap is economical way for cable management. It can be easily applied to wire harnesses, cables and wire bundles keep all your wires tidy and beautiful. It also serves as protection from damage.
Technical data
Material: PE
Operating range:-40C~80℃
Color: Black, Natural, white
Features

Simply fix one end by hand first ,then wrapped around the cable in a clockwise direction and tighten it up.

Dimensions

Nominal size OD(mm)	Wraping range (mm)	Packing (m/bag)
Φ4	1-10	10
Φ6	4-50	10
Φ8	6-60	10
Φ10	7-60	10
Φ12	9-65	10
Φ14	9-70	10
Φ16	12-75	10
Φ18	15-85	10
Φ20	15-100	10
Φ22	15-110	10
Φ25	20-130	10
Φ28	22-140	10
Φ30	26-150	10
