Applications
DM-PPS is a self extinguishing, Polyphenylene Sulfide 0,25mm monofila-ment, expandable braided sleeve.
DM-PPS offers a continuous working temperature of -50°C up to +200°C, an excellent mechanical abrasion resistance as well as a low level of flammability and a high resistance to most automotive fluids.
Features
It is suitable for protecting cables, pipes and hoses situated within harsh environments. Used within the automotive, aerospace and military sectors. Product available upon request.
Standard color: Black, natural.

Technical Data

Property	Values	Test Methods
Working temperature	-50C to+200℃
Peak temperature	+240℃
Melting point	+250℃
Chemical ;Fluid resistance	Unaffected by most chemicals	D471924
Flammability	Self extinguishing	FMVSS 302
	Type B	D451333

Dimensions

Nominal size (mm)			Expanded range (mm)
3.2			2.4-6.4
6.4			3.2-9.5
9.5			4.7-15.9
12.7			6.4-19.1
15.9			9.5-25.4
19.1			12.7-31.8
31.8			19.1-44.5
44.5			31.8-69.8
50.8			38.1-76.2
63.5			44.5-92.0

Available in spool, coils or cut pieces (on request).
Other packaging or diameter available upon request
