Applications
It is widely used to protect hydraulic pipes, rubber hose ,plastic pipes, wire harness from damage, this kind of sleeve can also be used in industrial and construction fields where outstanding hose productions are needed.
Features
Nylon textile protective sleeve consists of nylon multifilament. This kind of tublar sleeves are uniquely designed and ideal for protecting people, environment and machinery against any possible hydraulic hose oil leakage or spill. The tight woven construction can provide excellent abrasion resistance and high degree of burst resistance.
Certification: MSHA

Technical Data

Material	Nylon multifilament
Operating range	- 60°C-+125℃
Melt point	220±10℃
Crop tool	Scissor and hot knife
Certificate	RoHS, MSHA

Specification

Model	Flat Width (mm)	Diameter Max. (mm)	Standard length m/spool
DS-FT	20	12	50
	25	15
	30	18
	35	21
	40	24
	45	28
	50	31
	60	37
	70	44
	80	50
	90	56
	100	62
	115	72
	145	90
	176	110

*special spool lengths or cut pieces available on request.
