Applications
Most commonly used over wire harnesses, cable assemblies, flat ribbon cables, tubes and hoses to provide a tough, durable protection in automotive, automatic equipment, railways and panel boards.
Features
self-wrapping sleeve is a non-expandable sleeving woven from monofilament weft and multifilament warp polyester yarns. It provides a lightweight, cost-effective and tough solution for the protection of a wide range of components. Its inherent flexibility allows it to bend, coil and conform to irregular shapes, while its open design allows it to be installed on completed assemblies.

Color: black and grey

Technical Data

Material	Polyester monofilament and multifilament
Operating range	- 50°C-+150℃
Melt point	240±10℃
Fammability	VW-1
Certificate	ROHS,Halogen free

Dimensions

Size	Max. bundle Dia(mm)	Packing (L)
5.0	6.0	100m
8.0	9.0	100m
10.0	11.0	100m
13.0	14.0	50m
19.0	20.0	25m
25.0	27.0	25m
29.0	31.0	25m
32.0	34.0	25m
38.0	40.0	25m
50.0	52.0	25m

*special spool lengths or cut pieces available on request.
